Optoelectronics & Photonics Solutions

A photonic integrated circuit (PIC), also known as an integrated optical circuit, is similar to an electronic integrated circuit. However, instead of using only electrical signals to transmit information, these optoelectronic devices use both electrical and optical (light) signals. The use of optics enables more bandwidth and faster connectivity while reducing power costs. Optical components are well established in telecommunications and are technologies that provide connectivity for homes. The growth in data center applications has greatly increased demand for PICs since they enable more efficient system architectures, significantly reduce energy consumption, and improve performance. As such, the use of optoelectronic systems is expected to continue growing and requires cost-effective, reliable manufacturing solutions.


Optoelectronics & Photonics

Our Solutions

Coventor Product Family

Plasma Modeling Semiconductor Process Modeling

Our semiconductor process modeling software (SEMulator3D) and plasma modeling software (OverViz) perform predictive modeling of etch, deposition, plasma & other processes, to identify problems prior to fabrication.

DSiE Product Family

Deep Reactive Ion Etch (DRIE)

These products deliver exceptional process control at high productivity for several critical and non-critical deep silicon etch applications.

DV-Prime & Da Vinci Product Families

Wet Clean/Strip/Etch

These products provide the process flexibility needed with high productivity to address multiple wafer cleaning steps throughout manufacturing.

Flex Product Family

Atomic Layer Etch (ALE) Reactive Ion Etch (RIE)

Our dielectric etch systems offer application-focused capabilities for creating a wide range of challenging structures in advanced devices.

Galaxy Product Family

Wet Clean/Strip/Etch

The Galaxy platform combines years of experience in batch wafer processing with advanced process control typically only found on single wafer tools.

Kallisto Product Family

Dielectric Developement Electrochemical Deposition (ECD) PR-Development PR-Strip Wet Clean/Strip/Etch

An advanced vertical processing platform for wet chemical treatment of substrates from 300x300mm up to Gen 5.1 (1100 x 1300mm) tailored to the needs of semi industry.

OverViz

Plasma Modeling

OverViz™ is an industrial simulation software platform for high-fidelity modeling of plasma discharges.

Phoenix Product Family

Dielectric Developement Electrochemical Deposition (ECD) PR-Development PR-Strip Wet Clean/Strip/Etch

Phoenix offers a fully-automated high volume panel processing for 510x515mm substrates.

Reliant Clean Products

Reliant Systems Wet Clean/Strip/Etch

Our Reliant clean products enable roadmaps for Specialty Technologies and extend the productive life of fabs.

Reliant Deposition Products

Chemical Vapor Deposition (CVD) High-Density Plasma Chemical Vapor Deposition (HDP-CVD) Plasma-Enhanced Chemical Vapor Deposition (PECVD) Pulsed Laser Deposition (PLD) Reliant Systems

Our Reliant deposition products enable roadmaps for Specialty Technologies and extend the productive life of fabs.

Reliant Etch Products

Deep Reactive Ion Etch (DRIE) Reactive Ion Etch (RIE) Reliant Systems

Our Reliant etch products enable roadmaps for Specialty Technologies and extend the productive life of fabs.

SEMulator3D

Semiconductor Process Modeling

SEMulator3D® is a semiconductor process modeling platform that offers wide ranging technology development capabilities.

Sense.i Product Family

Atomic Layer Etch (ALE) Deep Reactive Ion Etch (DRIE)

Our latest etch platform offers unparalleled system intelligence in a compact, high-density architecture to deliver process performance at the highest productivity.

SP Series Product Family

Wet Clean/Strip/Etch

This proven product family delivers reliable, cost-efficient wet clean/wet etch solutions that gently remove unwanted materials from the wafer.

SPEED Product Family

High-Density Plasma Chemical Vapor Deposition (HDP-CVD)

These dielectric deposition products provide complete gapfill of high aspect ratio spaces with industry-leading throughput and reliability.

Triton Product Family

Electrochemical Deposition (ECD) Wet Clean/Strip/Etch

The Triton platform is a versatile and modular solution for single wafer plating and wet processing.

VECTOR Product Family

Plasma-Enhanced Chemical Vapor Deposition (PECVD)

Our PECVD product family provides precise dielectric film deposition at high productivity for a wide range of device applications.
